ANALISIS PENGARUH JUMLAH CARBON BLACK 90, 93, 95 PHR TERHADAP SIFAT FISIK DAN MEKANIK UNTUK APLIKASI SEAL O-RING

WERDHABUDI, JANOTTAMA (2025) ANALISIS PENGARUH JUMLAH CARBON BLACK 90, 93, 95 PHR TERHADAP SIFAT FISIK DAN MEKANIK UNTUK APLIKASI SEAL O-RING. S1 thesis, Universitas Mercu Buana Jakarta.

[img]
Preview
Text (HAL COVER)
01 COVER.pdf

Download (931kB) | Preview
[img] Text (BAB I)
02 BAB 1.pdf
Restricted to Registered users only

Download (211kB)
[img] Text (BAB II)
03 BAB 2.pdf
Restricted to Registered users only

Download (1MB)
[img] Text (BAB III)
04 BAB 3.pdf
Restricted to Registered users only

Download (833kB)
[img] Text (BAB IV)
05 BAB 4.pdf
Restricted to Registered users only

Download (972kB)
[img] Text (BAB V)
06 BAB 5.pdf
Restricted to Registered users only

Download (125kB)
[img] Text (DAFTAR PUSTAKA)
07 DAFTAR PUSTAKA.pdf
Restricted to Registered users only

Download (218kB)
[img] Text (LAMPIRAN)
08 LAMPIRAN.pdf
Restricted to Registered users only

Download (280kB)

Abstract

During the development of O-ring seal products for oil filter housing applications, PT XYZ Indonesia encountered an issue with hardness values that did not comply with the JIS B 2401 Class 1A technical specification. The original rubber compound formulation containing 83 phr of carbon black exhibited a hardness value of 63 Shore A, tensile strength of 17.83 MPa, and elongation at break of 703% under normal conditions. To improve the hardness performance, a reinforcing filler—carbon black N774—was added at concentrations of 90, 93, and 95 phr. This study aims to develop, test, and analyze the effect of using these concentrations on the physical and mechanical properties of rubber compounds intended for O-ring seal applications. The research began with the formulation design, compound fabrication, rheometer testing, vulcanization, and evaluation of physical and mechanical characteristics. The results showed that the hardness value of Formula 1 (CB 90 phr) was 70 Shore A, and Formula 2 (CB 93 phr) reached 72 Shore A. However, Formula 3 (CB 95 phr) failed to meet the JIS B 2401 Class 1A specification. The use of carbon black significantly influenced the hardness, tensile strength, elongation at break, compression set, heat aging resistance, and oil resistance (IRM 901 and IRM 903) of the rubber compound. Key word : Carbon Black, O-Ring Seal, Phr, Mechanical Properties, Physical Properties PT XYZ Indonesia pada saat pengembangan produk seal o-ring untuk rumah filter oli memiliki masalah terhadap nilai kekerasan yang tidak sesuai spesifikasi teknik JIS B 2401 kelas 1A. Kompon karet dengan formula original yang mengandung carbon black sebesar 83 phr menunjukkan nilai kekerasan sebesar 63 Shore A, kekuatan tarik sebesar 17,83 MPa, dan nilai perpanjangan putus sebesar 703% pada kondisi normal. Untuk meningkatkan nilai kekerasannya maka dilakukan penambahan bahan pengisi yaitu carbon black N774 dengan jumlah 90, 93 dan 95 Phr. Tujuan dari penelitian ini adalah untuk mengembangkan, menguji dan menganalisa hasil penggunaan 90, 93 dan 95 Phr terhadap sifat fisik dan mekanik kompon karet untuk aplikasi seal o-ring. Penelitian diawali dengan melakukan perancangan formula kompon karet, melakukan pembuatan kompon karet, rheometer test, pembuatan vulkanisat, pengujian sifat fisik dan mekanik. Hasil dari penelitian ini adalah nilai kekerasan formula 1 (CB 90 Phr) memiliki nilai kekerasan 70 shore A dan nilai kekerasan formula 2 (CB 93 Phr) memiliki nilai kekerasan 72 shore A. Untuk Formula 3 (CB 95 Phr) tidak memenuhi spesifikasi teknik JIS B2401 kelas 1A. penggunaan carbon black berpengaruh terhadap nilai kekerasan, kekuatan tarik, perpanjangan putus, pemampatan tetap, ketahanan pengusangan panas, ketahanan terhadap minyak IRM 901 dan 903. Kata kunci : Carbon Black, Seal O-Ring, Phr , Sifat Mekanik, Sifat Fisik

Item Type: Thesis (S1)
Call Number CD: FT/MSN. 25 110
NIM/NIDN Creators: 41323110030
Uncontrolled Keywords: Carbon Black, Seal O-Ring, Phr , Sifat Mekanik, Sifat Fisik
Subjects: 600 Technology/Teknologi > 620 Engineering and Applied Operations/Ilmu Teknik dan operasi Terapan > 621 Applied Physics/Fisika terapan > 621.8 Machine Engineering, Machinery/Teknik Mesin
600 Technology/Teknologi > 660 Chemical Engineering and Related Technologies/Teknologi Kimia dan Ilmu yang Berkaitan
600 Technology/Teknologi > 670 Manufacturing/Manufaktur, Pabrik-pabrik > 678 Elastometers Products/Produksi Elastometer > 678.4 Properties of Rubber/Sifat-sifat Karet
Divisions: Fakultas Teknik > Teknik Mesin
Depositing User: khalimah
Date Deposited: 23 Sep 2025 09:07
Last Modified: 23 Sep 2025 09:07
URI: http://repository.mercubuana.ac.id/id/eprint/98419
