SAURANG, MOH. AGYM HAIQAL R. (2025) PERANCANGAN ALAT PERAGA PLTA PIKOHIDRO MENGGUNAKAN GENERATOR DC. S1 thesis, Universitas Mercu Buana Jakarta.
|
Text (HAL COVER)
01 COVER.pdf Download (469kB) | Preview |
|
![]() |
Text (BAB I)
02 BAB 1.pdf Restricted to Registered users only Download (35kB) |
|
![]() |
Text (BAB II)
03 BAB 2.pdf Restricted to Registered users only Download (232kB) |
|
![]() |
Text (BAB III)
04 BAB 3.pdf Restricted to Registered users only Download (59kB) |
|
![]() |
Text (BAB IV)
05 BAB 4.pdf Restricted to Registered users only Download (120kB) |
|
![]() |
Text (BAB V)
06 BAB 5.pdf Restricted to Registered users only Download (29kB) |
|
![]() |
Text (DAFTAR PUSTAKA)
07 DAFTAR PUSTAKA.pdf Restricted to Registered users only Download (33kB) |
|
![]() |
Text (LAMPIRAN)
08 LAMPIRAN.pdf Restricted to Registered users only Download (486kB) |
Abstract
PikoHydro Power Plant (PLTPH) is one of the alternative solutions to meet electricity needs in remote areas that are not yet connected to the national power grid. In this final project, a small-scale PLTPH prototype was designed and built by utilizing the potential energy of flowing water to drive a turbine, which in turn rotates a DC generator. The system consists of a water reservoir, water pump, turbine, DC generator, solar charge controller (SCC), Leoch 12V 9.0Ah battery, single switch, and a 9-watt DC lamp as the load. The frame of the device is made from aluminum, which is lightweight yet strong and weather-resistant. Water from the reservoir is pumped to the turbine, generating rotation that drives the generator. The resulting DC current is regulated by the SCC to charge the battery. The stored energy is then used to power the DC lamp. The electrical system is designed with integrated wiring for easy assembly and efficient operation. Test results show that the device can generate a stable voltage of 12 volts with a power output between 150–200 watts. The maximum water flow rate reaches 1.68 liters per second at 392 RPM, with the 68-liter tank filling in approximately 40 seconds. Based on these results, the PLTPH prototype is considered feasible and efficient as a small-scale, environmentally friendly alternative energy source. Keywords: Pikohydro power, water turbine, DC generator, alternative energy, small-scale electricity generation. Pembangkit Listrik Tenaga PikoHidro (PLTPH) merupakan salah satu solusi alternatif dalam memenuhi kebutuhan energi listrik, terutama di daerah terpencil yang belum terjangkau jaringan listrik. Pada tugas akhir ini, dirancang dan dibuat sebuah prototipe PLTPH yang menggunakan turbin sebagai penggerak utama, dengan energi berasal dari aliran air. Sistem ini terdiri dari beberapa komponen utama, yaitu bak penampungan air, pompa air, turbin, generator DC, solar charge controller (SCC), aki 12V 9.0Ah, saklar tunggal, dan lampu DC 9 watt sebagai beban. Alat ini dirancang menggunakan rangka berbahan aluminium yang ringan namun kuat, sehingga mampu bertahan terhadap kondisi lingkungan luar seperti hujan dan panas. Air dari bak penampungan dialirkan melalui pompa menuju turbin, yang kemudian memutar generator untuk menghasilkan listrik arus searah (DC). Listrik yang dihasilkan dialirkan ke SCC untuk mengatur pengisian daya ke aki, dan energi dari aki digunakan untuk menyalakan lampu DC. Sistem kelistrikan dirancang menggunakan metode wiring yang menghubungkan seluruh komponen agar dapat berfungsi secara efisien dan terintegrasi. Hasil pengujian menunjukkan bahwa prototipe mampu menghasilkan tegangan DC yang stabil pada kisaran 12 volt, dengan daya sekitar 150–200 watt, dan dapat menyalakan lampu selama kurang lebih 12 jam. Debit air maksimum mencapai 1,68 liter/detik pada RPM 392, dengan waktu pengisian bak 68 liter sekitar 40 detik. Dari pengujian tersebut, dapat disimpulkan bahwa prototipe PLTPH ini layak digunakan sebagai sumber energi alternatif skala kecil yang efisien dan ramah lingkungan. Kata kunci: PLTPH, turbin air, generator DC, energi alternatif, pembangkit listrik Piko hidro.
Item Type: | Thesis (S1) |
---|---|
Call Number CD: | FT/ELK. 25 098 |
NIM/NIDN Creators: | 41421010025 |
Uncontrolled Keywords: | PLTPH, turbin air, generator DC, energi alternatif, pembangkit listrik Piko hidro. |
Subjects: | 600 Technology/Teknologi > 620 Engineering and Applied Operations/Ilmu Teknik dan operasi Terapan > 621 Applied Physics/Fisika terapan > 621.3 Electrical Engineering, Lighting, Superconductivity, Magnetic Engineering, Applied Optics, Paraphotic Technology, Electronics Communications Engineering, Computers/Teknik Elektro, Pencahayaan, Superkonduktivitas, Teknik Magnetik, Optik Terapan, Tekn 600 Technology/Teknologi > 690 Buildings/Teknik Bangunan > 696 Energy and Environmental of Building/Pengaturan Energi dan Lingkungan Sekitar Bangunan |
Divisions: | Fakultas Teknik > Teknik Elektro |
Depositing User: | khalimah |
Date Deposited: | 22 Sep 2025 08:07 |
Last Modified: | 22 Sep 2025 08:07 |
URI: | http://repository.mercubuana.ac.id/id/eprint/98319 |
