PERANCANGAN CHARGING SPOT MENGGUNAKAN PANEL SURYA SEBAGAI SARANA PENGISIAN PERANGKAT ELEKTRONIK DI AREA PUBLIK BERBASIS LOCALHOST UNTUK MEDIA MONITORING

PURBA, DAVIT RONALDO (2025) PERANCANGAN CHARGING SPOT MENGGUNAKAN PANEL SURYA SEBAGAI SARANA PENGISIAN PERANGKAT ELEKTRONIK DI AREA PUBLIK BERBASIS LOCALHOST UNTUK MEDIA MONITORING. S1 thesis, Universitas Mercu Buana Jakarta.

Preview	Text (HAL COVER) 01 COVER.pdf Download (688kB) | Preview
	Text (BAB I) 02 BAB 1.pdf Restricted to Registered users only Download (252kB)
	Text (BAB II) 03 BAB 2.pdf Restricted to Registered users only Download (503kB)
	Text (BAB III) 04 BAB 3.pdf Restricted to Registered users only Download (554kB)
	Text (BAB IV) 05 BAB 4.pdf Restricted to Registered users only Download (1MB)
	Text (BAB V) 06 BAB 5.pdf Restricted to Registered users only Download (177kB)
	Text (DAFTAR PUSTAKA) 07 DAFTAR PUSTAKA.pdf Restricted to Registered users only Download (246kB)
	Text (LAMPIRAN) 08 LAMPIRAN.pdf Restricted to Registered users only Download (355kB)

Abstract

“Design of a Solar-Powered Charging Spot for Public Electronic Device Charging with a Localhost-Based Monitoring System” is a study focused on the design and implementation of a charging facility for electronic devices utilizing solar energy as the main power source. This project aims to provide an energyefficient and environmentally friendly charging solution that can be applied in public areas to promote the use of renewable energy. The system employs a 120 Wp monocrystalline solar panel connected to a 20A solar charge controller to regulate the charging process of a 12 V 45 Ah VRLA battery. The stored energy is converted into AC power through a 500 W inverter, enabling the charging of low-power electronic devices. An ESP32 microcontroller and INA219 sensor are integrated into the system to allow real-time monitoring of voltage, current, and power, with data logging managed via localhost phpMyAdmin. The frame structure is constructed from hollow steel with aluminium composite panel cladding to ensure strength and weather resistance. Field tests conducted on August 12–14, 2025, demonstrated stable system performance. The average daily voltage ranged from 12.3 to 12.57 V, the average power output ranged from 19.7 to 25.0 W, and the average charging current ranged from 1.57 to 2.04 A. Peak performance occurred at midday when solar radiation was at its maximum level. Keywords: Solar panel, charging spot, ESP32, renewable energy, real-time monitoring. “Perancangan Charging Spot Menggunakan Panel Surya Sebagai Sarana Pengisian Perangkat Elektronik Di Area Publik Berbasis Localhost Untuk Media Monitoring” adalah penelitian yang mengulas perancangan dan implementasi fasilitas pengisian daya perangkat elektronik yang mengandalkan energi surya sebagai sumber utama. Proyek ini dikembangkan untuk menyediakan sarana pengisian daya yang hemat energi, ramah lingkungan, dan dapat diterapkan di area publik sebagai bagian dari upaya pemanfaatan energi terbarukan. Perangkat ini memanfaatkan panel surya monocrystalline berkapasitas 120 Wp yang terhubung dengan solar charge controller 20A guna mengatur aliran daya menuju baterai VRLA 12 V 45 Ah. Energi yang tersimpan di baterai dikonversi menjadi arus AC melalui inverter 500 W sehingga dapat digunakan untuk mengisi daya perangkat elektronik berdaya rendah. Sistem juga dilengkapi modul ESP32 dan sensor INA219 yang memungkinkan pemantauan tegangan, arus, dan daya secara real-time, dengan pencatatan data melalui localhost phpMyAdmin. Struktur penopang dirancang menggunakan besi hollow dan aluminium composite panel untuk memastikan kekuatan dan ketahanan terhadap kondisi cuaca. Pengujian lapangan yang dilakukan pada 12–14 Agustus 2025 menunjukkan kinerja sistem yang konsisten. Nilai rata-rata harian tegangan berada pada kisaran 12,3–12,57 V, daya pada kisaran 19,7–25,0 W, serta arus pengisian pada kisaran 1,57–2,04 A. Puncak kinerja sistem terjadi pada siang hari saat intensitas cahaya matahari berada pada titik tertinggi. Kata kunci: Panel surya, charging spot, ESP32, energi terbarukan, pemantauan

Item Type:	Thesis (S1)
Call Number CD:	FT/ELK. 25 058
NIM/NIDN Creators:	41421010015
Uncontrolled Keywords:	Panel surya, charging spot, ESP32, energi terbarukan, pemantauan
Subjects:	000 Computer Science, Information and General Works/Ilmu Komputer, Informasi, dan Karya Umum > 000. Computer Science, Information and General Works/Ilmu Komputer, Informasi, dan Karya Umum > 004 Data Processing, Computer Science/Pemrosesan Data, Ilmu Komputer, Teknik Informatika > 004.9 Nonelectronic Data Processing/Pemrosesan Data Non Elektronik 300 Social Science/Ilmu-ilmu Sosial > 300. Social Science/Ilmu-ilmu Sosial > 303 Social Process/Proses Sosial > 303.3 Coordination and Control/Koordinasi dan Kontrol > 303.38 Public Opinion/Opini Publik 500 Natural Science and Mathematics/Ilmu-ilmu Alam dan Matematika > 520 Comprehensive Works of Astronomy/Karya Komprehensif tentang Astronomi > 523 Specific Celestial Bodies/Benda-benda Angkasa Khusus > 523.7 Sun/Matahari, Surya 600 Technology/Teknologi > 620 Engineering and Applied Operations/Ilmu Teknik dan operasi Terapan > 621 Applied Physics/Fisika terapan > 621.3 Electrical Engineering, Lighting, Superconductivity, Magnetic Engineering, Applied Optics, Paraphotic Technology, Electronics Communications Engineering, Computers/Teknik Elektro, Pencahayaan, Superkonduktivitas, Teknik Magnetik, Optik Terapan, Tekn
Divisions:	Fakultas Teknik > Teknik Elektro
Depositing User:	khalimah
Date Deposited:	25 Aug 2025 01:38
Last Modified:	25 Aug 2025 01:38
URI:	http://repository.mercubuana.ac.id/id/eprint/97045
